硬盘型号：ST1000DX001--1NS162
故障现象：硬盘通不认盘，这种是固混盘，里面有很多套用友帐套的数据在里面，客户硬盘坏了之后，通过网络搜索，发现我们公司之前有过同样的成功案例，联系上我们确认之后 ，就直接坐动车来到武汉，要求我们尽快恢复。
解决方案：收到硬盘后，接到专业的数据恢复工具PC-3000 UDMA Express上，通电检测发现，终端信息如下：
Spin issued
TCC:0016
Rst 0x40M
Servo Processor Is Reset.
SOC PSM Mode = 0001 Atomic
SOC PSM Command = 0000 Flash Read
SOC PSM Status = 0001 ECC Error
Clump Parametrics:
Clump = 0040
DataType = 001A
ModeFlag = 01
EraseCount = 000074C3
EraseFailCount = 00
ProgramFailCount = 00
WeakReadCount = 1F
UncorrectableECCError = 07
---SOC PSM Command History---
Cmd#/PsmCmd Clump Offset Length LbaMid LbaLow LbaBits39To32 Options Status DestClump DestOffset
0000 0040 0F80 0009 8000 0810 0000 C000 0001 C207 AF6B
0900 0040 0F80 0009 8000 0810 0000 C000 0001 C207 AF6B
0800 019A 0010 0008 8000 175A 0000 C000 0080 C207 AF6B
0700 0015 0000 0800 8000 0000 0080 C000 0080 C207 AF6B
0601 01A0 06D0 0010 0000 0000 0000 C000 0080 C207 AF6B
Flash Statistics:
BridgePSMDriverID = 0x0006
FlashID ECA7 947E 64C4
Flash Manufacturer: Samsung
Flash Capacity = 00008 GB MLC
Combo Mode
NumberOfClumps = 0x0800
LBAsPerCluster = 0x0010
LBAsPerClumpMLC = 0x2000
LBAsPerClumpSLC = 0x1000
ClustersPerClumpMLC = 0x0200
ClustersPerClumpSLC = 0x0100
DefragClumpThresholdInSectors = 0x1000
UserSLCMaxSizeInClumps = 0x0300
NumberOfPotentiallyWrittenClusters = 0x0004
DefectListRevisionKey 0x0002
SLC Clumps 0x0342
SIM Error 101F LBA 0000000000000000 FD 08424093
RW Error 00000000
Table Recovery Faked and Completed
6Gb Max Speed lowered to 3Gb for Intel bug
Send Status: COMRESET seen
通过固件分析、处理，最后硬盘正常认盘，DE镜像，成功恢复客户的所有用友数据库文件及其它工作数据！
